Overview
Lamella clarifiers use packs of inclined plates to create enormous effective settling area in a compact tank. Solids settle on plates and slide to a hopper while clear effluent overflows.
How It Works
Process flow and treatment mechanism in simple steps:
- 1
Pre-treated water flows upward between closely spaced inclined plates.
- 2
Solids settle on plate surfaces and slide down into the sludge hopper.
- 3
Clear water continues upward and exits over outlet weirs.
- 4
Sludge is discharged periodically for further handling.
Applications
Industries and situations where this product is ideal:
- Primary and secondary clarification
- Metal hydroxide precipitation
- Desalination pre-treatment
- Capacity upgrades in limited space
Technical Highlights
Sizes, flow capacities, material options and design notes:
- 90–95% settleable TSS removal
- Up to 10× projected settling area vs open tanks
- Reduced civil work and installation time
- SS304, SS316, FRP or mild steel construction
- TSS removal
- 90 – 95%
- Flow range
- 5 – 250 m³/hr
- Plate angle
- 55° – 60°
- Plate material
- PP / SS
Specifications are indicative. Final design is engineered to your effluent and site conditions.
Photo Gallery
Fabrication, site installation and commissioning photography. Click any image to preview full size.
Case Study
Oil & Gas · Middle East
Major Gulf Region Refinery
Two 1,009 m³/hr lamella clarifiers handle extreme TDS and high-temperature degassed water pre-treatment.
Read full case studyGet Quote
Share the following details with our engineers for a tailored proposal for your Lamella Clarifier requirement:
- Design flow and inlet TSS
- Outlet clarity required
- Available footprint
- Plate material preference
Need this system sized for your plant?
Tell us about your effluent and operating conditions — our engineers will respond with a tailored proposal.
